ADVANCED TEMPERATURE PROFILING
By accurately controlling the temperature profile of the espresso extraction, baristas are given a precise tool to unlock the flavor potential of each single origin coffee or blend.
Each stainless steel group contains a micro-boiler and two heating elements, maximizing accuracy and thermal stability for both the water temperature and group body.
NNOVATIVE BREW GROUP HYDRAULICS
The RS1 features an innovative brewing group that maximizes efficiency and can introduce fresh water into the grouphead micro-boiler with every shot.
➊ COLD WATER | ➋ PROFILING SOLENOID | ➌ HOT WATER | ➍ GROUP SOLENOID | ➎ MICRO-BOILER | ➏ PRE-INFUSION CHAMBER | ➐ SHOWER | ➑ COFFEE
VARIABLE STEAM LEVER
Steam pressure delivery features a purge function and two programmable positions per side, perfect for switching between various pitcher sizes and different types of milk.
PORTAFILTER
New stainless steel, weight balanced portafilters with a soft touch, ergonomic grip. Designed to sit flat for stable and consistent tamping.
LOW PROFILE BODY
Compact, low profile body designed to facilitate customer interaction and service operations.
GROUPHEAD WITH DEDICATED DISPLAY
Dedicated screen for each brew group displays a digital shot clock and extraction temperature. Groupheads also feature simplified actuation and ample lighting provided by LED Lights.
DIGITAL TOUCHSCREEN INTERFACE
TECH FRIENDLY DESIGN WITH ECO MODE
Easy access to pump adjustment and internal components, arranged to speed up maintenance operations. Insulated steam boiler with programmable water renewal and low power and eco mode.
Easy access to pump adjustment and internal components, arranged to speed up maintenance operations. Insulated steam boiler with programmable water renewal and low power and eco mode.
WATER BUTTONS
Two water buttons with programmable dosage and temperatures levels.
COOL TOUCH STEAM WANDS
Cool touch steam wands ensure easy maneuverability when things heat up, and new proprietary steam tips allow for more even development.
3 GROUPHEADS
W X D X H1084 × 600 × 463 MM
WEIGHT110KG / 242.5 LB
TOTAL POWER6750 W
SERVICE BOILER CAPACITY16 L / 3.5 GAL UK / 4.2 GAL US
GENERAL SPECIFICATIONS
WORK SURFACE DEPTH180 MM / 7.0 IN
UNDER MACHINE HEIGHT90 MM / 3,5 IN
HEIGHT OF THE DRIP TRAY80*-100-120 MM / 3*-4-5 IN
VOLTAGE220-240 V / 380-415 V (3N)
FREQUENCY50/60 HZ
